Technical parameters
|
|
Standard
|
IEEE802.3i,
IEEE802.3u, IEEE802.3x
|
|
Network
protocol
|
ICMP,
IP, TCP, UDP, DHCP, Telnet, DNS, SNMP, HTTP, SMTP, ARP
|
|
Security
protocol
|
DES,
3DES, AES, SSH
|
|
Configuration
Method
|
WEB, Telnet,WINDOWS
UTILITY
|
|
Operating mode
|
Standard:
Real COM,TCP Server, TCP Client, UDP,Pair Connection Reverse Telnet
|
|
Interface
|
|
Interface
form
|
100M TX port:10/100Base-TX self-adaptive
RJ45 port
|
|
Serial port: RS-232/RS-485,Industrial Terminals
|
|
Ethernet
Port: 10/100Base-TX,RJ45 port(Support
auto-negotiation,support MDX/MDIX )
|
|
Serial port
|
Interface electrical characteristics: 2-wire RS-485 related standard
|
|
Data bit: 5 , 6 , 7 , 8
|
|
Stop bit:1 , 1 , 5 , 2
|
|
Check Digit: None, Even,Odd,Space,Mark
|
|
Flow Control: RTS/CTS,DTR/DSR,XON/XOFF
|
|
Baud rate: 300bps~460800bps
|
Serial protection: Full signal built-in 15KV ESD protection, RS-485 2KV fiber isolation protection
|
|
Power
indicator
|
|
System operation light
|
Ready
|
|
Power
Led light
|
Power
|
|
Network
indicator light
|
Link/Act
|
|
Serial port transceiver indicator
|
RX,TX
|
|
Power
|
|
Power Supply
|
DC5V/DC6-60V
|
|
Power
protection
|
Reverse
power polarity protection
|
|
Physical Characteristics
|
|
Shell
|
Aluminium alloy shell
|
|
Installation
|
Desktop
,rack mount installation
|
|
Dimension
|
TSD308: 201.5mmx105mmx30mm
Standard Rack Mount: 438.5mmx259mmx44mm
|
|
Weight
|
0.3kg
|
|
Transmission
distance
|
|
Serial
port line
|
RS-232, 1.2m@9600bps
|
|
Twisted-pair
|
100m(CAT5/CAT5e
cable)
|
|
Working Environment
|
|
Operating
Temperature
|
-20°C~70°C
|
|
Storage temperature
|
-20°C~85°C
|
|
Ambient Humidity
|
5%~95%
|
|
Warranty
|
|
Warranty
|
3 Years
|
|
Certification
|
|
Certification
|
CE, FCC
|
